Designed to meet the requirements of medium sized professional public address installations, delivering an output power of 60W RMS.

Availability: Available Usually Dispatched In: 2 - 5 Business Days Product Code: ALT-A4043 ISBN: 9321758227763 Brand/Publisher: Redback Categories: Professional Audio,

Part of the series PA Amplifiers.

View all products in this series

Designed to meet the requirements of medium sized professional public address installations, delivering an output power of 60W RMS. Frequency response extends from 60Hz to 15kHz at a total harmonic distortion (THD) of less than 0.5%. Features include, VOX muting, three balanced XLR microphone inputs, three line RCA inputs, bass and treble controls, enabling a diversity of installation applications, including schools, public halls, workshops and sporting complexes. Inbuilt VOX muting allows input 1 (mic or line) to mute inputs 2-3 and input 2 (mic or line) to mute input 3.

Powered from 240V AC mains or 24V DC permitting battery backup operation during mains power failure. Output is 100V line only. All units feature thermal overload shutdown to protect the amplifier if a speaker fault condition develops.

A 4573 Alert/evac option board: When fitted, generates pre chime, bell, alert and evacuation tones. The alert tone can function continuously, or switch to evac tone after a preset time delay (adjustable 30 seconds to 4.5 minutes). Simply connects to the amplifier internally via the cable provided.

A 4373 Digital remote volume option board: When fitted and used in conjunction with A 2280B wallplate to provide remote volume level adjustment. Ideal for situations where the amplifier is located in a remote rack.

Features

3 balanced microphone inputs
Phantom power on mic inputs
3 line inputs
19" rack mount kit included
VOX muting
Tape output RCA sockets
Bass and treble tone controls
100V line output
240V AC or 24V DC operation
Built in short circuit protection
10 year warranty
Optional evac module available
Optional remote volume module
Australian designed & assembled

100% developed, designed & assembled in Australia.
Since 1976 Redback PA products have been manufactured in Perth, Western Australia by Altronics. With over 40 years experience in the commercial audio industry, we offer consultants, installers and end users reliable products of high build quality with local product support.

Backed by an industry leading 10 Year Manufacturer Warranty.
Our Redback products have a long tried and tested history of bulletproof reliability. Altronics offers a 10 Year Warranty on all Australian Made Redback products. Our local in-house service department has all the know how to answer technical queries and provide timely service.
