Part of the series PA Speakers.
View all products in this series
Includes 22µF capacitor for line monitoring applications. The perfect choice for harsh industrial environments.
A wide operating temperature range and IP67 rated enclosure makes this horn suitable for a vast range of applications. The housing is UV stabilised which allows exposure to full sun. Several power taps are available via multi core cable, including 100V and 8Ω selections. Includes stainless steel hardware. Audio performance has not been sacrificed with excellent efficiency & frequency response. Suitable for flush ceiling mounting.
Features
- IP67 dust & moisture rated
- UV stabilised
- -30°C to 70°C for harsh environments
- 8 Ohm or 100V tappings
- Recessed bracket with stainless steel hardware
Backed by an industry leading 5 Year Speaker Performance Warranty.
This speaker is covered by our 5 Year speaker performance warranty. Redback PA drivers are engineered and manufactured to stringent specifications ensuring maximum reliability under all operating conditions. Each driver has a power rating well above the max tapping of the transformer, ensuring reliable operation and excellent longevity.
Specifications
- Rated Power (rms): 12W
- Impedance: 833Ω, 1.67kΩ, 3.33kΩ, 6.67kΩ and 8Ω
- Power Taps @ 100V: 12W, 6W, 3W, 1.5W & 8Ω
- Power Taps @ 70V: 6W, 3W, 1.5W, 0.75W & 8Ω
- SPL (1W / 1m) @1kHz: 98dB
- Max. SPL (Rated W / 1m) @1kHz: 109dB
- Frequency Range (-10dB): 570 Hz ~ 4.8k Hz
- Frequency Range (-20dB): 510 Hz ~ 12k Hz
- Dispersion 1k Hz / 4k Hz: 185˚/ 45˚
- Operating Temperature: -30˚C ~ +70˚C
- Ingress Protection: IEC 529 IP 67
- Power Selection: 6-core cable
- Housing material: High impact ABS with UV stable
- Colour / Finish: Light grey (RAL 7035)
- Dimensions: 143Ø. X 110.0L mm
- Cutout size: 110Ø mm
- Mounting: U-bracket or surface mount
- Net Weight (ea): 1kg
- *Specifications are subject to change without notice.
